HT Italia THT300 Advanced infrared thermal camera 388x284px
THT300 is the new professional thermal imaging camera equipped with a high resolution 384 x 288pxl IR sensor which makes it suitable for use in electrical, mechanical, plumbing, ventilation and refrigeration systems. It is equipped with a measuring range of -20 ° C ÷ 650.0 ° C and a field of view of 41.5 ° x 31.1 °, producing high quality thermal images and videos, as well as allowing AutoFusion and Picture in Picture functions. The thermal imaging camera is equipped with a modern internal icon structure and a high brightness capacitive touch-screen display.
It is also equipped with Wi-Fi connection, as well as being compatible with the new and convenient HT Pro Camera application.
| IR Resolution | 384×288 pxl |
| Temperature range | -20° ÷ 650°C |
| Image frequency | 50Hz |
| Thermal sensitivity / NETD | <0.05°C @ 30°C / 50mK |
| Field of view (FOV) | 41.5° x 31.1° |
| Focal length | f 1.0 |
| Lens | 9mm |
| IFOV | 1.89mrad |
| Focus mode | Manual Focus |
| Built-in camera | 2 MP, focus free |
| Picture in Picture function | ● |
| AutoFusion image enhancement | ● |
| Uncertainty about the measure | ±2°C (±3.6°F) o±2% de ler |
| Digital zoom | 1x ÷ 32x |
| Measurement tools (in live mode) | none, center spot, 3 spots, hot/cold spots, 3 areas, vertical and horizontal lines, screening mode |
| Area measurement information | max, min, AVG |
| IR Video recording | ● |
| Measurement corrections | emissivity, reflected temperature, ambient temperature, atmospheric humidity, infrared compensation, distance compensation |
| Color Palettes | iron, rainbow, white hot, black hot, brown hot, blue/red, hot/cold, feather, above max alarm, below min alarm, interval alarm |
| Internal memory | 3,4 GB |
| On-camera report building | text annotation |
| Communication modes | USB type C, Wi-fi, SD card |
| Display | touch screen |
| Battery operation time | 4 hours |
| Size (LxWxH) (mm) | 240 x 101 x 110mm |
